Kvant Lasers Berry Lite RGB Laser System

The Kvant Lasers Berry Lite RGB Laser System fully equipped 5W full-color RGB laser display system with build-in 3W LED blinder - that’s Kvant Berry Lite. With our Berry Lite, you can now easily create all the super-cool laser effects that seemed impossible to accomplish before. Controlling a complex setup made of many Berries is now so simple thanks to the control via Art Net protocol.

Modular Laser/Lighting Fixture

This system is designed to work as a multi-head laser projector and can be assembled into virtually any geometrical formation - offering phenomenal graphical performance.

What is in the Package

Laser projector

Hanging bracket

Mains cable

Ethernet cable

E-STOP with XLR cable

Interlock [US only]

Safety keys

USB drive with Manual

QC Certificate

Product Specifications:

Source | Type: Semiconductor laser diode [FAC] | Full-color RGB laser projector with LED Blinder

Suitability: Indoor laser displays [atmospheric, abstract, text, animations]

System Control: FB4-STD [Ethernet, Art Net | PC, Lighting Console or Auto play]

Compliant With: EN 60825-1 [tested by TÜV SÜD], FDA

Guaranteed Opt. Output [Mw]: 5100

R | G | B [Mw]: 1200 | 1700 | 2400 [see note A below]

Wavelengths [Nm, ±5nm]: 637 | 520 | 445

Beam Size [Mm]: 6x5

Beam Divergence [Mrad]: 1.5 [full angle, averaged value, see note B below]

Modulation [Khz] | Type: 100 | analogue

X-Y Scanners: ScannerMAX 506 Compact | 35 Kpps @ 8°, max. 50°

Power Requirements [V] | Input: 100-230/50-60Hz | Neutrik powerCON TRUE1

Max. Power Consumption [VA]: 200

Operation Temperature [°C]: 10-35

Exterior Dimensions (L X W X H): 6.73 X 6.73 X 14.13"

Weight: 8.37 Lb
