Furman CN-2400S 20A Smart Sequencing Power Conditioner

The Furman CN-2400S 20A Smart Sequencing Power Conditioner combines robust control capabilities via Smart Sequencing Technology, advanced AC protection, AC noise filtration, and optional compatibility with the Blue BOLT Remote Power and Energy Management Platform (BB-RS232 adaptor required, sold separately).

The new CN-2400S is one of the first products to feature Furman’s Smart Sequencing™ technology, which allows large and complex A/V systems to be safely powered on and off with a simple press of a button or turn of a key, even by nontechnical personnel. Smart Sequencing’s bidirectional communications between installed units enables a primary unit to control and sequence multiple secondary units, ensuring multizone electronic systems are powered on and off safely and dependably from a single control point across an entire installation. Units can be connected via current loop at runs of more than 1,000 feet with backwards compatibility with Furman’s legacy sequencers.

In addition, the CN-2400S offers robust control options, equipped with RS-232 ports and command sets for integration with control systems. An optional RS-232-to-Ethernet adaptor (sold separately) adds full IP-addressability to the unit, allowing it to be controlled, programmed, and monitored from a smartphone, tablet, PC, or any Web-enabled device via Telnet, direct HTTP: connection, or Panamax/Furman’s Blue BOLT-hosted remote power and energy management platform.

Product Specification:

Form Factor: Rackmount

Type: Conditioner

Rated Current: 20 A

Number of Circuits: Not Specified by Manufacturer

Metering: None

Battery Backup: No

Typical Backup Runtime: Not Specified by Manufacturer

Integrated Lamps: None

Rackmount Size: 1 RU

Cable Length: 10' / 3 m

Wire Gauge: 12 AWG

Dimensions: 19 x 10.5 x 1.7" / 48.2 x 43.1 x 26.6 cm

Weight: 12 lb / 5.4 kg

Package Weight: 13.2 lb

Box Dimensions (LxWxH): 21.5 x 14.5 x 4.5"
